| Type |
Digital exposure meter for ambient & flash light |
| Sensor |
SPD (Silicon photo diodes) measuring head with swivel/ lumisphere for incident; optional 5° viewfinder for reflected |
| Display |
2.7″ color touchscreen LCD |
| Measuring Modes (Ambient Light) |
T priority, F priority, TF priority; HD CINE (T priority), CINE (f/s priority); Lux/Foot-Candle; Cd/m²/Foot-Lambert |
| Measuring Modes (Flash Light) |
Cordless, Cord-in (PC Sync), Multiple cumulative flash readings |
| Measuring Range (ISO100 Ambient Incident) |
EV-2 to EV22.9; 0.63 lx to 2,000,000 lx; 0.1 fc to 180,000 fc |
| Measuring Range (ISO100 Ambient Reflected) |
EV3 to EV22.9; 1.0 cd/m² to 980,000 cd/m²; 0.29 fl to 290,000 fl |
| Measuring Range (Flash Incident Light) |
f/1.0 to f/161.2 (~128.9) at ISO100 |
| Measuring Range (Flash Reflected Light) |
f/2.8 to f/161.2 (~128.9) at ISO100 |
| ISO Range |
ISO 3 to ISO 409,600 + ISO 850 |
| Aperture Range (Ambient Light) |
f/0.5 to f/161.2 (~128.9) in 1, 1/2, 1/3 step (Analog scale: f/1.0 to f/90 in 1/3 step) |
| Aperture Range (Flash Light) |
f/0.5 to f/161.2 (~128.9) in 1, 1/2, 1/3 step (Analog scale: f/1.0 to f/90 in 1/3 step) |
| Shutter Speed Range (Ambient Light) |
30 min to 1/64,000 s in 1, 1/2, 1/3 step (analog: 4 s to 1/2,000 s in 1/3 step) |
| Shutter Speed Range (Flash Light) |
30 min to 1/1,000 s in 1, 1/2, 1/3 step |
| Frame Rate Range (Ambient / Cine Modes) |
1 fps to 1,000 fps plus other custom settings from 0.001 fps to 9,999.999 fps |
| Shutter Angle Range (Ambient / Cine Modes) |
1° to 358° plus other custom settings from 0.001° to 360° |
| Memory / Functions |
Memory mode (8-9 readings); contrast/comparison (+/-9.9 EV in 1/10 step); filter compensation (-12 EV to +12 EV); exposure compensation (-9.9 EV to +9.9 EV); calibration compensation (-1.0 EV to +1.0 EV); custom settings (13 profiles) |
| Operating Temperature |
-10 °C to +50 °C |
| Storage Temperature |
-20 °C to +60 °C |
| Power Source |
2 × AAA batteries (1.5 V each) |
| Dimensions (approx.) |
140 mm × 57 mm × 26 mm (5.51″ × 2.24″ × 1.02″) approx. |
| Weight (approx.) |
0.13 kg (130 g) without batteries |
